Description
143kVA, 3 Phase, Standby Diesel Generator with Cummins Engine in Canopy
Model No.: ED143CuYE/3
The Cummins powered ED143CuYE/3 is a 143kVA three phase standby diesel generator. Complete with Crossley SLG series single bearing, 4-pole, brushless alternator, remote start/stop control system, 255 litre fuel tank, weather protective acoustic canopy and Cummins engine. Welling and Crossley Cummins powered generating sets are fully integrated power generation systems that are stringently tested to provide optimum performance, reliability, and versatility for standby applications.
Alternator
Alternator Model: Crossley SLG Series
Electric Power: Three Phase
Active Rating: 143 kVA at 0.8 pf (Standby)
Power: 114.4 kW
Voltage: 415V
Frequency: 50Hz
Engine
Engine Model: Cummins 6BTAA5.9G2
Engine Speed: 1500 rpm
Cylinder No.: 4TA
Cubic Capacity: 5.9 L
Bore / Stroke: 102 x 120 mm
Compression Ratio: 17.3 : 1
Aspiration: Turbocharged
Starter Voltage: 24V
Flywheel ( Max. Continuous Power): 119 kW
Combustion Air Flow: 12.6 m³/min
Cooling Air Flow: 560 m³/min
Cooling System: Radiator Cooled
Heat Rejection to Cooling System: 88 kW
Exhaust Gas Flow: 40 m³/min
Exhaust Gas Temperature: 550°C
Fuel Type: Diesel
Fuel Tank Capacity: 255 L
Approx. Fuel Consumption (Continuous): 26.5 L/hr
Approx. Fuel Consumption (Standby): 30 L/hr
Generator
Dimensions (L x W x H): 3200 x 1100 x 1570 mm (L x W x H)
Weight: 2070 kg
